ProAll P50 | Compact & Powerful Volumetric Mixer

P50 Overview

Don’t underestimate the ProAll P50. This 7-yard mobile concrete mixer is built for maneuverability, easily navigating tight city streets while delivering the same high throughput as larger models. Designed for a shorter wheelbase chassis, the P50 has the smallest footprint among our high-production mixers—yet it delivers an impressive 70m³/hr (90yd³/hr) output. When space is limited, the P50 delivers big performance in a small package.

PRODUCT INFORMATION SHEET

Control System

We began by unveiling our flagship control system, setting the standard as the most advanced offering in the industry. Now, we’re ushering in a new era of control with our groundbreaking technology: Commander 2.0 by ProAll – A Terex Brand. Featuring an intuitive graphical interface, it not only streamlines operations but also simplifies training, empowering operators to effortlessly achieve optimal results.

“The 2.0 is the interface we have been missing!”

– Ken Hardman, Advantage Concrete in Melbourne, Florida USA

Product Details

Technical Specifications

Production Capacity (m³/yd³)

5.4m³ / 7yd³

Production Rate (m³/hr) (yd³/hr)

70m³/hr (90yd³/hr)

Aggregate Bin (m³/yd³)

3.53m³ / 125ft³

Sand Bin (m³/yd³)

3.15m³ / 111ft³

Cement Bin (m³/yd³)

2.6m³ / 93ft³

Water Tank (L/US gal)

1500L / 400gal

Available Mixer Configurations

Custom Fit

Trailer Mounted

Standard Features

Two-way wireless remote:
Two-way, wireless, digital remote for easy operator use. Operate the mixer, make adjustments, or start and stop production, all with one easy to use remote.

Aluminum fenders for drive axles:
Checker plate aluminum fenders for the drive axles of the truck.

Automated two product admix system:
Two-product chemical admixture system. Once the mixer is calibrated, simply input how much of each admix chemical you require per yard and let the Commander do the rest. This automated admix system ensures you are getting the right amount chemical in every yard of concrete you pour. Standard tank sizes are 40L/10gal and 80L/20gal.

Electric Vibrators for sand, stone, and cement bins:
Two electric vibrators are mounted on the inside wall of the sand bin with an additional electric vibrator mounted on the exterior of the cement bin. The vibrators are automated and can be set to run at a predetermined interval to ensure a consistent flow of material.

Electric roll-up tarp:
An electric roll-up mesh tarp. A toggle switch on the side of the mixer is used to cover and uncover the aggregates.

Variable Speed Cement Metering (not limited to only 2 speeds):
The variable speed cement metering auger gives the control system the ability to automatically adjust the speed of the metering auger to meet the quantity of cement required for the selected mix design. This allows for use of multiple mix designs with various cement content without having to manually change gears or recalibrate.

Ticket Printer in cab of truck:
An electric roll-up printer is mounted in the cab of the truck and is used to print the details of a completed batch or job.

Automated Chain Oiler:
A container on the side of the mixer which is filled with oil automatically distributes oil to the chain of the belt at a predetermined number of belt rotations. How often and how long the chain oiler is engaged can be modified using the on-board control system.

Automated water system with manual override:
No more chasing your slump. The Commander’s automated water system ensures you are getting the exact amount of water required for the selected mix design. The system also has a manual override so adjustments can be made as needed.

Additional Options

1-Year Spare Parts Package for P Models – 9″ Auger

1-Year Spare Parts Package for P Models – 12″ Auger

Additional Automated Admix System: available in 40L/10gal, 80L/35gal)

Aluminum Tool Box (admix-mounted)

Aluminum Toolbox (bought-out)

Aerator System for Single Cement Bin

Aggregate Bin Liner

Aluminum Fenders (does not include lift axel fenders/super single)

Auto Lube System

Belt Material Sensors

Cement Bin Safety Rail

Cement Low-Level Sensor

Color Feeder

Custom Paint

Dual Water Tank Fill

Large 133 Cubic Foot Cement Bin

Extra Large 186 Cubic Foot Cement Bin

Fiber Feeder – Pre-Chopped

Fiber Feeder – Standard

Gate Height Verification Sensors

Severe Duty Belt

High/Low Cement Bin Sensor/Light Package

Mix Bowl Cover

Mixer Diaper

Pressure Washer

Rear Ladder & Platform 13″ Standard

Swivel Chute

Upgrade to 100/71 Hydraulic Pump (Standard 71/45)

Upgrade to 9″ x 116″ Mixing Auger

Upgrade to 12″ Mixing Auger

Insulated Water Tank

Washout Kit

Water Level Sensor

Water Tank Safety Rail

Additional Work Lights: Four Additional Flood Lights

White Noise Alarm

Backup Camera with 7″ HD Screen (3 Inputs) with Single Camera and Audio

Backup Camera with 7″ Standard DefScreen (1 Input) with Single Camera

Additional Camera W Connector for HD Assembley

Upsize Water Lines: Deliver up to 68gal/min to Mix Bowl
